Hydraulic swing arm clicker press die cutting machine
Hydraulic swing arm clicker press die cutting machine
Usage and features:
1,Suitable for molding cutter die blanking, cutting operations on a variety of non metallic materials.
2,Automatic cutting stroke adjustment: change the knife mold height without any adjustment.
3,Fast speed, low energy consumption.
4,Casting body, long service life, low noise.
Technical Specifications:
|
Model |
GSB-2C/10 |
GSB-2C/12 |
GSB-2C/16 |
GSB-2C/200 |
|
Max. Cutting Force |
100KN |
120KN |
160KN |
200KN |
|
Max scissoning force |
0.10m/s |
0.098m/s |
0.10m/s |
0.10m/s |
|
Seissor speed |
5-75mm |
5-60mm |
5-75mm |
5-75mm |
|
Stroke adjustment |
60-120mm |
60-120mm |
65-150mm |
65-150mm |
|
Distance between upper table and lower able |
400*800mm |
400*900mm |
450*900mm |
500*1000mm |
|
Overall dimension |
850*700*1250mm |
900*800*1300mm |
900*900*1380mm |
1000*900*1380mm |
|
Motor power |
0.75KW |
1.1KW |
1.1KW |
1.5KW |
